Application :

» Blown Film Extruder Corona Treater,
» Sheet Extruder Corona Treater,
» Label Corona Treater,
» Flexo Printing Machine Corona Treater,

Technical Information

• » Aluminium Electrode with Aluminium Roll and Silicon Sleeve for None-Conductive Material ( LDPE,HDPE,PP,OPP etc)
  » Single Surface or Both 2 Surfaces  treatment
  » Zero Speed Sensor in order to know if the web is broken or not
  » Oil Cooled High Voltage Transformer
  » Ozone Extractor Blower ( AC Motor type)
  » Different Voltage Levels are possible depen on the country voltage level, 1 Phase 110-120-220-230 Volts or 3 Phases 220-230-380-400-415 Volts
  » For 50-60 Hz Frequence Input
  » Pot in order to control output power
  » Output Current Indicator
  » Audio Indicators for a Short circuit, Film Broken, no output etc.
  » No Power on ouput  if there is a Short circuit, Film Broken etc.



  Type	Roller Width	Electrode Width	Segmented Electrodes (Piano Keys)	Aluminium Roller and Silicone Sleeve	Material Type (None Conductive)	Aplication	Zero speed Sensor	Output Power Control
  EAG-600	600 mm	600 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-700	700 mm	700 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-800	800 mm	800 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-900	900 mm	900 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-1000	1000 mm	1000 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-1100	1100 mm	1100 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-1200	1200 mm	1200 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-1300	1300 mm	1300 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-1400	1400 mm	1400 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-1500	1500 mm	1500 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-1600	1600 mm	1600 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-1700	1700 mm	1700 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-1800	1800 mm	1800 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-1900	1900 mm	1900 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-2000	2000 mm	2000 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-2100	2100 mm	2100 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-2200	2200 mm	2200 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-2300	2300 mm	2300 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-2400	2400 mm	2400 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-2500	2500 mm	2500 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
  EAG-2600	2600 mm	2600 mm	Yes	Yes	PE, HDPE,LDPE, PP	Plastic Film Extrusions	Yes	Yes
